Facade cladding with architectural wire mesh
Car park of the Exhibition Centre Bologna
It was important that the mesh elements could be tensioned continuously over the full height of the façade without any visual interruptions. Also the substructure had to be minimal and mainly consists of top and bottom fixing points. The resulting building envelope with its transparency and reflections sets a visual cause and simultaneously allows sufficient ventilation through the apertures of the mesh. Furthermore it remains recognisable as car park for the visitors.
In total more than 9,000 m² of mesh type EGLA-MONO 4251 were installed. The open area of approx. 69% allows the required ventilation, as well as creating exceptional light reflections, giving a unique appearance of high value to the building. The standard mesh elements with a height of 12.20 m and a width of 2.20 m were supplied by Haver & Boecker ready for installation, complete with tensioning devices which consist of flat tension profiles, clevis screws and pressure springs. As a result the installation process was simple and time-saving. The corrosion resistant stainless steel wire assures not only the high quality appearance but also offers longevity to the whole construction.
The total volume of the complex is impressive: 140 meters wide, 220 meters long and five storeys high, offering plenty of space for exhibition visitors.
