Finder 13 Series: Three new impulse relays to expand wiring possibilities

More connection options, new functions, and the same compact footprint: Finder introduces three new electronic impulse relays to the 13 Series for lighting control.

The new models 13.9C.8.230.0000, 13.91.8.230.0040, and 13.95.8.230.0040 feature terminal blocks with a higher pin count, offering installers additional wiring options without increasing the overall size of the device.

These relays can be flush-mounted behind push-buttons within junction boxes, in wall-mounted boxes, or, using a special adapter, panel or surface-mounted.

All new models handle contact ratings up to 10 A and comply with EN 60669-1 and EN 60669-2-1 standards.

Three versions to suit different control needs:

- Type 13.9C.8.230.0000: Step relay with dual terminals. Suitable for controlling LED lamps with power ratings up to 300 W.

- Type 13.91.8.230.0040: Dual-function relay operating in either step or timed relay modes (time settings available for 2 seconds, 6 minutes, or 10 minutes). Equipped with a Reset terminal for centralized switching off, and supports LED lamp loads up to 300 W.

- Type 13.95.8.230.0040: Sequential impulse relay with 2 outputs and 4 sequences with step function. Also features a Reset terminal for centralized switching off, supporting LED lamp loads up to 250 W.

New functions for a historic range
With this evolution, Finder reaffirms its role as a benchmark in relay manufacturing and electrical system innovation, offering installers and designers the ideal combination of versatility, quick installation, and compliance with the highest quality standards—ensuring efficient and customized solutions for any installation context.

Technical documentation and further information are available at findernet.com.
